1
RESEARCH and DEVELOPMENT
The purpose of this arrangement is to have skills that are not just limited to know-how in hydraulics, but also has expertise in two other key aspects of the best materials and the use of electronic command and control systems: the overall perspective is to optimize performance, safety e sustainability.
OUR TEAM
WHY RESEARCH & DEVELOPMENT
Research new technologies and skills not yet in use in our company.1
Provide continuous support to all other departments in design, analysis, and problem solving.2
Conduct simulation studies using tools such as CFD, FEM, and a concentrated parameter software for fluid dynamics analysis.3
WORK IN PROGRESSINNOVATION
PJRDL14 PLUG & PLAY CONFIGURABLE VALVE DRIVER
Configurable valve driver2 PWM outputClosed loop feedback with current monitoringAnalog or CAN bus input (SAEJ1939)Input voltage: 9-36 V Maximum output current: 3A (for each channel)
VALVE DESIGN ENGINEERING
2
VALVE DESIGNENGINEERING
Our Valve Design Engineering Team is committed to the re-design of VIS standard products, with an emphasis on customer customization.
The common feature of the different valves designed by this team is the continuous improvement of product performance.
Versatility, speed, and design efficiency are supported by simulations and structural calculations, under product warranty.
OUR TEAM
9
Valve Design EngineerA team of young minds with expertise on coils, hydraulics, and mechanics, who go out of their way to meet specific customer requests about product customizations.
WORK IN PROGRESSINNOVATION
PJ0838DIRECTIONAL CARTRIDGE SOLENOID VALVE, 4-WAY/3-POSITION, SPOOL, DIRECT ACTING
The rigid design using a one-piece body and tube helps in minimizing the effect of eccentricities while still ensuring verified reliability. Pressure drops are reduced as a result of optimized flow paths.
Maximum working pressure: 250 barMaximum operating flow rate: 13 l/minMaximum internal leakage: 200 cm3/min @ 250 barProof pressure: 388 barBurst pressure: >765 barCoils: 20.5W Weight: 0.175 kg
WORK IN PROGRESSINNOVATION
COIL CCROADIRECTIONAL CARTRIDGE SOLENOID VALVE, 4-WAY/3-POSITION, SPOOL, DIRECT ACTING
Metal parts are protected by oxidation according to the RoHS directive.Suitable for applications on pilots of different sizes. Possibility of customizing the connector and laser marking.
Power: 14 W – 26 W Voltage: 12 V - 28 V Degree of protection: IP69K
DESIGN ENGINEERING
3
DESIGNENGINEERING
The Design Engineering Team (DE) provides expertise to manage new and technologically challenging customer requests while following the stages of innovative products design.
OUR TEAM
1
Product design by performing simulations and by using concentrated parameter software, FEM, CFD, and in-house expertise.
2
Constant commitment to anticipate potential market innovations.
WHYDESIGN ENGINEERING
3
Continuous technical support to customers and constant dialogue with them that allows us to optimize the design of our solutions, according to their needs.
WORK IN PROGRESSINNOVATION
PJ0870ELECTRO-PROPORTIONAL PRESSURE RELIEF VALVE WITH PRESSURE SETTING INVERSELY PROPORTIONAL TO CURRENT
Continuous current regulation makes this valve the ideal solution for retroactive control of fan drive cooling systems inside medium to large transport vehicles such as buses. The net energy savings due to temperature optimization is a key element in energy-saving systems.
WORK IN PROGRESSINNOVATION
PJ0628ELECTRO-PROPORTIONAL FLOW RATE REGULATOR, PRESSURE COMPENSATED
The integration of concentrated-parameter simulation systems with FEM simulations enabled the design of this valve to be optimized, with the objective of faster response times. Fundamental is the linear trend of the flow-rate control curve, wanting to have uniform velocity control that is directly related to the uniform flow rate trend. The main application is within lifting and lowering systems, and because of its multifunctionality it allows compact and efficient systems to be created.
MANUFACTURING ENGINEERING
4
MANUFACTURINGENGINEERING
Support production departments with putting new products into production.
Perform risk analysis in collaboration with quality Depts and line managers
Participation in problem solving activities in cooperation with quality and all production departments.
s
OUR TEAM
WHYMANUFACTURING ENGINEERING
Production departments are experiencing a real revolution and the Manufacturing Engineering department is right in the center of it all by implementing:
1
Statistical Process Control for all mechanical machining
2
Goal of zero defect for the final product achieved by utilizing six sigma methodology along with controls, sensors, and automation to support operators.
WORK IN PROGRESSMANUFACTURING ENGINEERING
SEMI-AUTOMATIONDESIGNED AND BUILT THROUGH IN-HOUSE COMPANY EXPERTISE
DO & CHECK CONCEPT Semi-automatic assembly of valves with two separate stations. Inside the machine there are control gates that ensure complete conformity of the product after each stage since the next stage cannot be carried out until all previous steps are properly completed.
ROTARY TABLE CELL Semi-automatic machine for final assembly of a valve by checking its compliance before each stage resulting in complete customer satisfaction.
TESTING DEPARTMENT
5
TESTINGDEPARTMENT
Our Testing Lab is a strong example of innovation and a continuous pursuit of excellence in order to fully satisfy our customers through strict validation criteria that accompany our products from their inception.
CABABILITIES

The department was always equipped with the best equipment on the market, investing more each year on custom machinery that could fulfill our needs and perform any test required by our customers. Enthusiasm and cross-functional skills are the backbone of this department, aimed at ensuring the highest quality through experimental performance trials and endurance tests, in order to obtain robust and detailed validations.

4 ENDURANCE TEST BENCHES

3 EXPERIMENTAL BENCHES

1 BURST TEST BENCH

1 CLIMATIC CHAMBER

OUR TEAM

Over the years our Test Lab has grown through the induction of young technicians who continue to bring their own ambition and enthusiasm into the department, fueling a steady growth in expertise through continuous collaboration with the design teams.

PROTOTYPE SHOP
6
PROTOTYPESHOP
The Prototype department, located in our Innovation Center, consists of 5 turning machine operators who are highly skilled and experienced. They are distinguished by their passion and willingness to never stop learning and continuously improve, always aiming to produce the perfect component.

Responsive execution

High accuracy by closely working with our internal Quality team.

Diversity of knowledge to enable them to manage various types of components and equipments.

OUR TEAM
CABABILITIES

1 MACHINING CENTER

1 MANUAL LATHE

3 CNC BAR LATHES

1 CNC SHOOTING LATHE

QUALITY AND DIGITALIZATION
1

CUSTOMER QUALITY
andQUALITY ASSURANCE

The Customer Quality team is responsible for providing customer support on after-sale product quality issues and new product validation, managing the necessary quality documentation, and monitoring the key performance indicators required by our customers.

The Quality Assurance team manages the constant updating and monitoring of the mandatory regulations that govern our industry.

2

CMM
COORDINATE MEASURING MACHINE

Automatic coordinate measuring machineVersatile machine because it allows multiple dimensions to be processedPrecise and accurateFaster speed in measurement and lead time reportingImplementation of programs on the basis of Solid Works CAD design
3

CONTAMINATION

Automatic specimen washing bench that does not require continuous operator supervisionThe work cycle consists of washing and collecting the contaminants from the specimen and then measuring and quantifying the contaminantsSimplicity, speed and efficiency in measurement.
4

STATISTICAL
PROCESS CONTROL

QUARTA EVO is an integrated software for SPC (statistical process control) that is installed on every VIS production machine and enables data collection, processing, and control and re-planning of data in order to avoid the risk of process drift by intercepting special causes in a preventive way.

It allows for a direct link with on-board machine measuring instruments which then allows for real time monitoring of machining capabilities and process variables affecting dimensions and tolerances, thus enabling zero scrap.

LEAN MANAGEMENT
1
SIX SIGMA

The Six Sigma approach is a problem solving method that aims to improve quality and reduce costs and defects.

6

In 2024 alone, 6 strategic business projects were developed with Six Sigma methodology.

11

Collaborators who have obtained the Yellow Belt

12

Collaborators who have obtained the Green Belt

2

To further crown this initiative, VIS has the goal to train two business leaders to earn the Black Belt certification

2

PROJECT
IN COOPERATION WITH TOYOTA

The project was born from a collaboration between cross-functional teams from VIS Hydraulics and Toyota Engineering & Consulting and aims to reorganize and optimize the logistics at the main production plant (VIS1) in order to reduce lead times and increase flexibility and responsiveness to our customers' demands.

Results available to date show a 60% reduction in lead time.
