Solenoid operated, 2-way 2-positions, normally open, piloted poppet type, screw-in cartridge valve. Typically used as a blocking or load holding device for high pressure circuits. When the coil is de-energized, the SV10.S08 allows flow bidirectionally from 2 to 1, and from 1 to 2. When the coil is energized the valve closes, blocking flow from 2 to 1. In this mode, flow from 1 to 2 is allowed once the pressure overcomes the force of the solenoid. The rigid design using a 1-piece body contributes to minimize the effect of eccentricities in cavity and provides great reliability. Low pressure drop thanks to optimized flow path.

All external surfaces are zinc plated and corrosion-proof. All valve parts are made of high strength steel. Poppet is hardened and ground to ensure minimal wear and extended service life. Coil seals protect the solenoid system. Manual override option. Industry SAE common cavity.

The PFR0 is a proportional solenoid operated, twoway, poppet type, normally closed, screw-in hydraulic cartridge valve for low leakage blocking and load-holding applications. When de-energized, the valve operates as a check valve and allows flow from 1 to 2, while blocking flow from 2 to 1. When energized, the valve opens 2 to 1 flow path: flow is proportional to the current applied to the coil.

All External surfaces are zinc plated and corrosion proof. All valve parts are made of high strength steel. Poppet and seat are hardened and micron finished to guarantee minimal wear and to extend service life. Efficient wet armature design. Industry SAE common cavity.

The PCV is a screw-in, cartridge style, priority- on-demand, pressure compensator with a static load sense. The valve delivers required priority flow (0 to max. available) on demand to 4 regardless of load pressure; inlet flow is at 3. In idle position, the valve will deliver all input flow at 3 to the priority port 4. Increasing pressure at 4 (applied to the spool against the spring force) will result in an increasing excess flow exit at 2 (by-pass of input flow). Excess flow at 2 can be used for auxiliary functions. Port 1 is the load sense pressure port. Pressure at 1 assists the spring and moves the spool back so priority flow is supplied.

All external surfaces are zinc plated and corrosion- proof. All valve parts are made of high strength steel. Spool and cage are hardened and super-finished to ensure minimal wear and extended service life. Load sense is static (basing on spring load). Industry SAE common cavity.
